NT-PL501C
802.3af/at PoE standard
8-core power supply technology, reducing the power circuit loss
Data monitor and control for the important ports
EXTEND mode available to extend the network cable transmission distance to 250 meters
Buffer optimization to guarantee the video data transmission
VLAN configurable
Port trunk
STP, multicast and port mirroring
QoS
SNMP
WEB management
Store-and-forward switching
IEEE802.3, IEEE802.3u and IEEE802.3x network standards available
MTBF (Mean Time Between Failure) ≥ 100,000 hours
All-metal enclosed construction
Table-mounted and rack-mouted design for convenient installation
24*10/100 Base-TX Ethernet ports, one 10/100/1000 Base-T Ethernet port and one 10/100/1000 Base-X SFP optical module port
Ports 1 – 24 are 10/100 Mbps downlink ports and comply with IEEE 802.3af and IEEE 802.3at.
The maximum of 30W port output PoE power and the maximum of 225W total output PoE power
Support four network modes: Priority, Standard, Isolate and Extend
4K MAC address and MAC address learning
8.8 Gbps backplane bandwidth
Store-and-Forward switching
All-mental construction
13 inch length and 1 U standard height size allow it to be mounted on subrack.
Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3z, IEEE 802.1Q, and IEEE802.3x Ethernet standards
16*10/100 Base-TX Ethernet ports, one 10/100/1000 Base-T Ethernet port and one 10/100/1000 Base-X SFP optical module port
Ports 1 – 16 are 10/100 Mbps downlink ports and comply with IEEE 802.3af and IEEE 802.3at.
The maximum of 30W port output PoE power and the maximum of 135W total output PoE power
Support four network modes: Priority, Standard, Isolate and Extend
4K MAC address and MAC address learning
7.2 Gbps backplane bandwidth
Store-and-Forward switching
All-mental construction
13 inch length and 1 U standard height size allow it to be mounted on subrack.
